1. The difference between rotor flowmeter LZT and LZS
The main part of the cone tube of LZT panel flowmeter is made of AS and ABS plastic, which has good corrosion resistance, reasonable structure, small shielding volume, light weight, and the cone tube is not easy to break. LZT panel flowmeter can be widely used in industrial sectors such as chemical, environmental protection, and food. The Ziyou Automation Instrument Series panel can be divided into four connection methods for flow meters: plug-in, welding, threaded, and flange connection. The main part of the cone tube of LZS plastic flowmeter is made of AS and ABS plastic, which has good corrosion resistance, reasonable structure, small volume, light weight, and the cone tube is not easy to break. LZS plastic tube flowmeter can be widely used in industrial sectors such as chemical, environmental protection, and food. The Ziyou Automation Instrument Series flowmeter LZS plastic tube macro wheel flowmeter has two main types, namely long tube type and short tube type. Adopting a plastic shell, it has the ability to resist 30% acid and alkali corrosion.
2. Introduction to Plastic Rotary Flow Meter
The main part of the cone tube of LZB series plastic tube rotary flow meter is made of AS and ABS plastic, which has good corrosion resistance and features a structure that can withstand collapse, small volume, light weight, and the cone tube is not easily broken.
. Plastic tube rotor flowmeter can be widely used in industrial sectors such as chemical, environmental protection, and food. The characteristic of the shirt is that it is not wear-resistant and corrosion-resistant. It can be attached with specific scales, calibrated sizes, measurement ran_600x400.jpg)
3. Installation and use method of plastic tube rotor flowmeter
The installation and use method of LZS series plastic tube rotor flowmeter is as follows:
1. Installation method of Kuankai Brother: Connect directly by inserting and bonding: Use ABS or PVC plastic tube, directly insert into the flowmeter interface with special adhesive and fix it.
. Flange connection: If it needs to be connected to a metal pipeline, ABS or PVC flanges should be used to bond the flowmeter first, and then the flange should be connected to the metal pipeline to ensure sealing. Installation direction and angle perpendicular installation: The flowmeter must be installed vertically on the pipeline, with a tilt angle of less than 5 °, otherwise measurement errors may occur due to uneven force on the rotor. Direction identification: During installation, it is necessary to ensure that the flow direction arrow of the flowmeter is consistent with the actual flow direction of the medium. The straight pipe section requires an upstream straight pipe section: A straight pipe section of at least 5 times the diameter length should be reserved upstream of the flowmeter to eliminate interference from eddy currents or resistance in the pipeline and ensure data stability. Downstream straight pipe section: There is no strict limit on the length of the downstream straight pipe section, but it is recommended to reserve 2-3 times the diameter length to optimize the flow state. Adequate space should be reserved around the installation of the flo
