1. What parameters can a compressed air flow meter monitor?
A compressed air flow meter can monitor the following core parameters.
1. Basic flow parameters • Instantaneous flow: Real time monitoring of the flow rate of compressed air in the pipeline (unit: m ³/min or Nm ³/h) • Cumulative flow: Record the total amount of gas passing through the pipeline during a specific time period (unit: m ³ or Nm ³) • Mass flow: Some models can directly measure gas mass (unit: kg/h) 2. Operating condition parameters • Pressure value: Synchronized detection of gas pressure in the pipeline (usually 0-1.6 MPa) • Temperature value: Real time monitoring of gas temperature (typical range: -20 ℃~+80 ℃) • Dew point temperature: High end models can output compressed air humidity Parameter 3 Energy efficiency parameters • Flow rate: displays the gas flow velocity inside the pipeline (unit: m/s) • Compression ratio: calculated from pressure data • Leakage rate: detects system leakage through flow mutation analysis Advanced functional parameters (specific model support required) • Density compensation: automatically corrects flow data affected by temperature and pressure • Energy consumption: calculates energy consumption of compressed air system (kW · h/m ³) • Pulse output: converts flow signal into standard pulse signal (such as 4-20mA) • Note: The specific monitoring and measurement force depends on the equipment model, and thermal flow meters usually have more temperature monitoring functions than mechanical flow meters. In 2023, data from the Ministry of Industry and Information Technology showed that the detection error rate of mainstream model parameters was ≤ 1.5%.
2. What is the principle of gas flowmeter?
2>3. Which brand is more suitable for choosing a compressed air flow meter?When choosing a compressed air flow meter, you need to first clarify your accuracy requirements, budget, and after-sales service needs, and then match the brand accordingly. Reference for brand selection with different positioning • International first-line brands (high-end budget) are suitable for large and medium-sized enterprises with extremely high requirements for accuracy and long-term stability: 1 Enders Cracking Dust House (Switzerland): Industry benchmark, T-mass thermal mass flowmeter and vortex flowmeter have excellent reputation, high precision and strong anti-interference, perfect after-sales service, suitable for the automotive, chemical, and pharmaceutical industries. two Siemens (Germany): an industrial automation giant with strong adaptability to ultrasonic and thermal flow meters, which can be seamlessly integrated into Siemens PLC and DCS systems, suitable for factories that have already laid out Siemens automation systems. Tongyuan stared at 3 Emerson (USA): Its Micro Motion Coriolis flowmeter has top-notch accuracy and can simultaneously measure mass flow and density. Rosemounts vortex street and differential pressure flowmeters range from economical to top-level models, suitable for enterprises that pursue top-level performance or have a habit of using Emerson instruments. International professional/domestic leading brand (mid-range budget) balances performance and practicality: 1 Shanghai Aisite Instrument: focuses on compressed air and gas measurement, with a deep understanding of energy efficiency management and leak detection in air compression systems. Equipped with professional data recording and analysis s
