1. Calculation of Orifice Flow Meter
The core calculation formula of an orifice flow meter is qv=C × ε× A0 × √ (2 Δ p/ρ), and the calculation result directly reflects the flow rate.
1. Basic Parameter Analysis 1 Outflow coefficient C: It is related to the geometry of the orifice plate and the pressure measurement method, and needs to be obtained through experiments or by referring to standard charts. two The coefficient of expansion ε: for liquids, it is set to 1, while for gases, it needs to be corrected through charts based on pressure difference and temperature. three Opening area A0: calculated as A0=π d ²/4, where d is the measured inner diameter of the orifice plate. four Differential pressure Δ p: directly measured by a pressure sensor or U-tube, in Pa. 5. Density ρ: The density of the liquid is less affected by temperature, and the gas needs to be converted according to the working pressure and temperature.
2. Decomposition of Calculation Steps 1 Determine the fluid nature of the Mingshi field: distinguish between liquids or gases, and select the corresponding ε value. two Parameter measurement and acquisition: - Measure the diameter d of the orifice plate opening and calculate A0. - Record the reading Δ p of the pressure differential exciter. -Check the table or conduct experiments to determine C and ε. 3. Substitute into the formula for calculation: evaluate step by step according to qv=C ε A0 √ (2 Δ p/ρ).
III. Example Calculation of Water Flow Measurement in a Pump Pipeline: • Known Conditions: d=0.05m, Δ p=5000Pa, ρ=998kg/m ³ (20 ℃ water), C=0.62，ε=1。 • Calculation process: 1 A0=π× (0.05) ²/4 ≈ 0.00196m ². two Substitute into the formula: qv=0.62 × 1 × 0.00196 × √ (2 × 5000/998
2. How to calculate flow rate using temperature pressure compensation for orifice plate
The core of calculating flow rate through temperature pressure compensation for orifice plate flowmeter is to correct the fluid density deviation caused by changes in working conditions based on the measured temperature and pressure values, thereby obtaining accurate mass flow rate.
. 1. Calculation principle: Orifice flowmeter measures flow based on differential pressure principle, and its basic mass flow formula is \ (q_ {m}=\ alpha \ varepsilon d ^ {2} \ sqrt {2 \ Delta p \ rho_1} \). Among them\ (q_ {m} \) is the mass flow rate\ (\ alpha \) is the flow coefficient\ (\ varepsilon \) is the coefficient of expansion (1 for incompressible fluids)\ (d \) is the diameter of the orifice plate opening\ (\ Delta p \) is the measured differential pressure value, while \ (\ rho_ {1} \) is the density of the fluid under actual operating conditions. The core task of temperature and pressure compensation is to accurately calculate this \ (\ rho_ {1} \)2. The choice of temperature and pressure compensation method depends on the fluid medium. For g
